2019 John Deere 1200H Hydro

2019 John Deere 1200H Hydro

Bunker & Field Rake

• Fuel efficiency at speeds up to 10 mph

• Standard 72-inch rear rake enables rapid coverage

• Adjustable seat and wide running boards

• Stylish rear body

Features may include:

The hydrostatic 3WD system has variable speed for excellent pulling and pushing power

Instruments and electronic controls are positioned for easy reach and visibility:

• Ignition switch and key start are mounted on the console for quick and easy starting

• Choke control for quicker cool weather starts is conveniently located on the console at left

• Standard rear and mid implement lift lever is located on the right side for easy access

Raising the hinged rear fiberglass body cowling exposes the 16-hp*(11.9-kW), 479-cc air-cooled, overhead valve engine:

• High torque for pulling power

• Fuel efficient for lower operating cost and extended operating range

• 3.9 gal (14.8 L) gas tank for long hours of operation with unleaded gasoline

• Full pressure lubrication and oil filter for good reliability

• Low vibration for long component life and operator comfort

The forward and reverse foot pedals provide ease of identification and operation. The forward pedal is larger than the reverse pedal and provides good clearance for the operator's foot. This is the same two-pedal design used on the John Deere 2500A Riding Greens Mower

A heavy-duty air filter is standard equipment on the 1200A Bunker and Field Rake. Featuring a cyclone design, this dual element filter can eject 90 percent to 95 percent of dust particles before they reach the paper element core. This reduces overall maintenance costs through less cleaning and replacement

The operator's platform is designed for comfort, control, and high productivity:

• 14-in. (35.56-cm) diameter steering wheel with a 10-to-1 gear ratio for easy and responsive steering

• Adjustable for and aft for improved comfort for large and small operators

• Wide running boards for comfortable leg support of large and small operators alike

Wide high-flotation tires provide low ground compaction

All tires are 22x11.00x8 NHS

The 47-in. (119-cm) wheelbase enables a tight turning radius
